- Stock: In Stock
- Brand: HYTE
- Model: CS-HYTE-Y70TI-BB
🔧 Core Specifications
-
Type: Dual Chamber Mid-Tower ATX Case
-
Exterior Dimensions: 470 x 320 x 470 mm
-
Volume: 70.7 Liters
-
Motherboard Support: ITX / mATX / ATX / E-ATX
-
Expansion Slots: 7 Half + 4 Full Height
-
Included Riser Cable: PCIe 4.0 x16
-
Storage Support:
-
2x 3.5" HDD or
-
4x 2.5" SSD
-
-
Max GPU Length: 422 mm
-
Max GPU Thickness: 105 mm
-
Max CPU Cooler Height: 180 mm
-
Max PSU Length: 235 mm
-
Warranty: 4 Years
🌬️ Cooling Support
-
Top:
-
Fans: 3x 120 mm / 2x 140 mm
-
Radiator: 120–360 mm / 140–280 mm (up to 68 mm thick)
-
-
Rear:
-
Fans: 1x 120 mm / 1x 140 mm
-
Radiator: 1x 120 mm / 1x 140 mm
-
-
Side:
-
Fans: 3x 120 mm / 2x 140 mm
-
Radiator: 120–360 mm / 140–280 mm (up to 125 mm thick)
-
-
Bottom:
-
Fans: 3x 120 mm / 2x 140 mm (up to 32 mm thick)
-
-
Dust Filters: Top, Side, Bottom
🔌 Front I/O Ports
-
1x USB-C 3.2 Gen 2
-
2x USB-A 3.2 Gen 1
-
1x 3.5 mm Audio/Mic Combo Jack
📺 Built-in Display – HYTE Touch Nexus
-
Panel Type: IPS
-
Screen Size: 14.9 inches (Diagonal)
-
Resolution: 682 x 2560 (2.5K)
-
Brightness: 500 nits
-
Contrast Ratio: 1000:1
-
Viewing Angle: 80°
-
Pixel Density: 178 PPI
-
Touch: 10-Point Multi-Touch
-
Refresh Rate: 60 Hz
-
Response Time: 30 ms
-
Inputs:
-
USB 2.0 Header
-
SATA Power
-
DisplayPort
-
-
Powered by: Nexus Touch
🧩 Available Color Variants (SKU)
-
CS-HYTE-Y70TTI-BB
