Xpg Kyber 750w 80 Plus Gold

Power Supply – 650W / 750W / 850W (80+ Gold / Platinum)

Dimensions (L × W × H): 140 × 150 × 86 mm
Cybenetics Rating:

• 850W → Platinum

• 750W / 650W → Gold

80 Plus Rating: Gold
ATX Version:

• 850W / 750W → ATX 3.1

• 650W → ATX 2.4

Protections: OVP, OPP, SCP, OCP, UVP, OTP, NLO, SIP
Certifications: CB, TUV, cTUVus, CE+UKCA, FCC+IC, LVD+UKCA, BSMI, RCM, BIS, EAC+ROHS, S-MARK, NOM
PFC: >0.99

Electrical Specs

• Input Voltage: 100–240V

• Input Current:

  • 850W → 12A

  • 750W → 10A

  • 650W → 10A

• Input Frequency: 47–63Hz

DC Output Rails: +5V | +3.3V | +12V | -12V | +5Vsb
Total Power: 650W / 750W / 850W

Power Excursion:

• 850W → 1700W (up to 235% of rated power for 100µs)

• 750W → 1500W (up to 235% of rated power for 100µs)

Operating Temperature: 40°C

Cooling

• Fan Size: 120 × 120 × 25 mm

• Fan Bearing: FDB (Fluid Dynamic Bearing)

• Fan Speed: 2400 RPM

• MTBF: 100,000 hours

Connectors

• 1 × 24-pin ATX

• 2 × 8-pin EPS

• 2 × PCIe (6+2 pin) [all models]

• 2 × Molex (all models)

• SATA: 6 (all models)

• 12V-2x6 / 12VHPWR (12+4, 600W):

  • 850W → 1

  • 750W → 1

  • 650W → 0

Weight

• 850W → 2.032 kg

• 750W → 2.024 kg

• 650W → 1.768 kg
