🛠️ Specifications (Formatted)

🖥️ CPU & Chipset

• Socket: LGA 1851

• Chipset: Intel Z890

• Supported Processors: Intel® Core™ Ultra Series

🧠 Memory

• Memory Type: DDR5

• Memory Slots: 4 x DIMM

• Max Memory: Up to 256GB

• Memory Speed: Up to 9500 MT/s (OC)

• Dual Channel Support: Yes

• Special Features: ECC (non-ECC mode), XMP, CUDIMM, Intel EXPO support

🎮 Expansion Slots

• PCIe x16: 1 x PCIe 5.0 x16 slot (CPU)

• PCIe x4: 1 x PCIe 4.0 x4 slot (Chipset)

• PCIe x1: 1 x PCIe 4.0 x1 slot (Chipset)

💾 Storage

• M.2 Slots:

  • 1 x PCIe 5.0 x4 (CPU)

  • 1 x PCIe 4.0 x4 (CPU)

  • 3 x PCIe 4.0 x4/x2 (Chipset, includes SATA support)

• SATA Ports: 4 x SATA 6Gb/s

• RAID Support: RAID 0, 1, 5, 10 (for NVMe and SATA)

🌐 Networking

• LAN: Realtek® 5GbE LAN

• WiFi: Intel® WiFi 7 (802.11be)

• Bluetooth: Bluetooth 5.4

🔌 USB Connectivity

• Thunderbolt 4: 2 x USB4® Type-C® (rear)

• USB 3.2 Gen 2 Type-A: 2 ports (rear)

• USB 3.2 Gen 1: 6 ports (4 rear, 2 internal)

• USB 2.0: 8 ports (4 rear, 4 internal)

🎧 Audio

• Audio Codec: Realtek® ALC1220

• Channel Support: 2/4/5.1/7.1-channel HD Audio

• Special Features: DSD Audio, S/PDIF Out

🛠️ Internal I/O Connectors

• 2 x 8-pin ATX 12V Power Connectors

• 1 x 24-pin ATX Main Power Connector

• 5 x M.2 Sockets

• 4 x SATA Ports

• CPU/Water Pump/Chassis Fan Headers

• Addressable RGB Gen2 and RGB Strip Headers

• USB Type-C®, USB 3.2, USB 2.0 Headers

• Trusted Platform Module (TPM) Header

• Q-Flash Plus button

📏 Form Factor

• Form Factor: ATX

• Dimensions: 30.5 cm x 24.4 cm

• OS Support: Windows 11 64-bit
